Battery Analyzer
BM31012 V LED Battery & Charging System Tester
Check compatible 12 V lead-acid battery systems with LED indications for battery, starting and charging conditions. Clamp connection, reverse-polarity and overvoltage protection.
Product overview
The BM310 is a portable LED tester for initial checks on compatible 12 V vehicle lead-acid systems. Separate indicator areas help assess battery, starting and charging conditions during routine maintenance and pre-repair checks. Interpret results alongside connection quality, load, environment and vehicle service specifications.
Key capabilities
LED condition indications
Red, yellow and green LEDs indicate conditions in the relevant panel area. Follow the labels and manual; a color is not an exact capacity percentage.
Battery, starting and charging checks
Helps check battery condition, voltage behavior during starting and alternator charging after the engine starts. Each check requires the correct vehicle state and procedure; they are not a single simultaneous conclusion.
Clamp connection
Connect red to positive and black to negative with clean, secure contact. Follow the prescribed procedure for in-vehicle checks. This clamp version differs from cigarette-lighter or dual-adapter variants.
Portable housing and protection
An ABS housing supports portable use, with reverse-polarity and overvoltage protection. Confirm the system voltage; protection is not permission for incorrect wiring or use outside ratings.
Suggested workflow
Prepare and connect — Confirm a compatible 12 V lead-acid system and test conditions. Connect red positive/black negative as instructed, clear of moving parts.
Check each condition — Observe the panel in the specified battery-rest, cranking and engine-running steps. Charging voltage is not the same as resting battery condition.
Record and verify — If abnormal, check connections and conditions, then verify with a dedicated analyzer and service information as needed. Disconnect after use.
Frequently asked questions
Does it display CCA, resistance or precise SOH?
This model provides LED condition indications, not those numerical results. Choose a battery analyzer with the required measurements for quantitative testing.
Is it suitable for lithium batteries or other voltages?
Select it for the stated 12 V lead-acid application and verify battery type in the manual. Physical clamp fit does not establish lithium or other-voltage support.
Does a normal LED indication rule out every fault?
No. Intermittent faults, cold starting, connection issues and changing loads may require further checks. Consider symptoms, service limits and appropriate professional tests.
Product design

Documentation and support
Key features
Applications
Technical specifications
| Item | Specification or function |
|---|---|
| Model | BM310 |
| Nominal system voltage | 12 V |
| Battery application | Compatible flooded, AGM flat-plate, AGM spiral and GEL lead-acid batteries |
| Checks | Battery condition, starting behavior and alternator charging |
| Display | Red, yellow and green LED condition indicators |
| Connection | Battery clamps; red positive, black negative |
| Protection | Reverse-polarity and overvoltage protection |
| Housing | ABS |
| Body dimensions | 120 × 48 × 18.5 mm |
| Weight | ≈100 g |
LED indications are condition references, not actual Ah capacity, CCA or resistance readings. Follow this model’s manual for compatibility and operating conditions.
