Protable VCI

P0112V Wireless OBD2 Adapter for Codes & Live Data

Access standard emissions-related OBD2 data on compatible 12 V vehicles through a matching wireless version and phone app. Read/clear codes, live data and I/M; Bluetooth/Wi-Fi depends on the…

Product overview

The P01 is a wireless OBD2 adapter that connects to the vehicle’s 16-pin diagnostic port. A compatible phone app displays emissions-related engine faults and operating data. The adapter handles communication; interface, recording and report features depend on the app and ECU. Check wireless version, phone system and vehicle protocol before use.

Key capabilities

Standard OBD2 engine diagnosis

Compatible apps can read/clear emissions-related DTCs and show live data, freeze frames, I/M and vehicle information. Oxygen-sensor and Mode $06 tests require vehicle/app support; this is not manufacturer-specific full-system diagnosis.

Match the wireless version to the phone

Product material covers Bluetooth and Wi-Fi variants; this does not mean every unit includes both. iOS/Android compatibility depends on the actual wireless version, chosen app and current system requirements.

Compact plug-in design and data access

Plugs into the 16-pin OBD port and uses vehicle power, with four status LEDs. Available data items come from the ECU; voltage readings do not replace CCA, resistance or actual capacity testing.

Suggested workflow

  1. Confirm version and compatibility — Verify the 12 V vehicle’s OBDII/EOBD protocol, adapter wireless version and app requirements; connector shape or year alone is insufficient.

  2. Connect the phone app — Connect to the diagnostic port as instructed, select the matching Bluetooth or Wi-Fi method and follow the app’s current connection steps.

  3. Save before clearing — Save DTCs, freeze frames and relevant data before clearing as needed. Clearing may reset I/M status and does not repair the underlying fault.

Frequently asked questions

Does a 16-pin port or a post-1996 year guarantee support?

No. OBD requirements vary by market, fuel type and year. Check make, model, year, region and protocol; the same connector shape does not guarantee the required function.

Does it diagnose ABS/airbags or perform proprietary service resets?

This page covers standard emissions-related engine OBD2 use, without promising proprietary modules or resets. An app menu alone does not establish vehicle/adapter support.

What if the phone connects but no vehicle data appears?

Check ignition state, port contact, adapter selection and protocol settings in the app, plus wireless and vehicle compatibility. Phone-to-adapter connection does not confirm adapter-to-ECU communication.

Product design

P01 Product design

Documentation and support

View product documentation and contact technical support

Key features

Access standard emissions-related OBD2 data on compatible 12 V vehicles through a matching wireless version and phone app. Read/clear codes, live data and I/M; Bluetooth/Wi-Fi depends on the supplied version.

Applications

P01 12V wireless OBD2 adapter for engine codes, live data, freeze frames and I/M readiness through a compatible app. Bluetooth/Wi-Fi varies by version. Specs and FAQ.

Technical specifications

ItemSpecification or function
ModelP01
PurposeStandard OBDII/EOBD emissions-related engine interface
Nominal powerVehicle-powered 12 V OBD port; follow unit ratings
Connector16-pin OBD
Wireless methodBluetooth / Wi-Fi variants; confirm supplied configuration
Phone and softwareiOS/Android per wireless version/app compatibility; interface functions from app
ControllerPIC18F25K80
Crystal oscillator4 MHz
LEDs4 status indicators
Protocol familiesJ1850 PWM / J1850 VPW / ISO 9141 / ISO 14230 KWP / ISO 15765 CAN
Data functionsDTC read/clear, live data, freeze frames, I/M, VIN etc., per ECU/app
Standby currentApprox. 3 mA; varies by version and state
Body dimensions70 × 47 × 25 mm
Operating temperature−20–60°C
Storage temperature−40–85°C

Wireless hardware varies by version; verify the actual configuration and app compatibility. Diagnostic functions depend on ECU and software support.
