Brake Fluid Tester

BF200Backlit LCD Brake Fluid Moisture Tester for DOT3/4/5.1

DOT3, DOT4 and DOT5.1 moisture screening on a backlit LCD. Flexible illuminated probe, separate fluid/backlight/light controls, audible alerts and auto sleep aid reservoir checks.

Product overview

The BF200 screens moisture condition in compatible DOT3, DOT4 and DOT5.1 brake fluids and shows result levels on a backlit LCD. A flexible probe, LED lighting and separate fluid/light controls aid reservoir access. Results support maintenance; they do not directly measure boiling point or replace vehicle service intervals and braking-system checks.

Key capabilities

Backlit LCD and indication levels

The screen shows fluid selection and moisture-reference levels marked 0.5%, 1%, 2%, 3% and 4%. Lower levels provide a condition reference; at around 3% or above, verify and act promptly according to vehicle service requirements.

Flexible probe and separate lighting

The flexible probe reaches different positions, with separately controlled probe LEDs and LCD backlighting. Immerse only the sensing area as instructed and keep the main unit and controls dry.

Separate controls and power saving

Hold the power key for on/off, use MENU for fluid selection, S for LCD backlighting and the light key for probe illumination. Audible alerts and auto sleep complement 2 replaceable AAA batteries.

Suggested workflow

  1. Prepare and select — Confirm the specified fluid, install 2 AAA batteries, power on and use MENU to select the reservoir fluid.

  2. Clean and test — Clean the probe as instructed, illuminate the area and place the sensing portion in the fluid. Read when stable and avoid introducing contamination or other fluids.

  3. Record, verify and store — Record fluid type and level; verify or replace according to service requirements if abnormal. Wipe the probe, power off and store dry.

Frequently asked questions

Are DOT5 and DOT5.1 the same fluid?

No. Silicone-based DOT5 differs from non-silicone DOT5.1. Listed selections are DOT3, DOT4 and DOT5.1; do not extend compatibility to DOT5 or mineral fluids.

Is the percentage a precise continuous measurement?

It indicates reference levels; do not treat the scale as laboratory-precision continuous moisture analysis. Fluid setting, temperature and probe contamination affect results; verify with an appropriate professional method when needed.

Does it measure boiling point or diagnose every braking fault?

No. It screens fluid moisture condition, not boiling point, hydraulic pressure, wear or leaks. Those require the appropriate service checks.

Product design

BF200 Product design

Documentation and support

View product documentation and contact technical support

Key features

DOT3, DOT4 and DOT5.1 moisture screening on a backlit LCD. Flexible illuminated probe, separate fluid/backlight/light controls, audible alerts and auto sleep aid reservoir checks.

Applications

BF200 brake fluid moisture tester for DOT3/DOT4/DOT5.1 with backlit LCD, probe light and audible alerts. 156×55×24 mm, 2 AAA batteries. Specifications and FAQ.

Technical specifications

ItemSpecification or function
ModelBF200
PurposeStepped brake-fluid moisture-condition screening
Fluid selectionsDOT3 / DOT4 / DOT5.1
DisplayBacklit monochrome LCD
Indication levelsReference marks: 0.5%, 1%, 2%, 3%, 4%; around 3%+ replacement-alert range
Audible alertHigh-moisture indication alert
Probe and sensorFlexible metal hose and sensing probe
LightingIndependent LCD backlight and probe LED control
Power2 × AAA batteries
Power savingAuto sleep
Operating temperature−10–50°C
Dimensions156 × 55 × 24 mm
WeightApprox. 150 g including batteries
HousingABS
ControlsPower / MENU fluid / S backlight / probe light

Indicated percentages support screening; they are not boiling-point measurements or brake-safety certification. Use the correct fluid setting and follow vehicle service intervals and tool instructions.
