Brake Fluid Tester
BF100DOT3/DOT4/DOT5.1 Brake Fluid Moisture Tester
Three-color LEDs and five moisture-indication levels for DOT3, DOT4 and DOT5.1. Flexible probe with lighting, single-button fluid selection, audible alerts and auto sleep aid routine screeni…
Product overview
The BF100 provides initial moisture-condition screening for compatible DOT3, DOT4 and DOT5.1 brake fluids. A flexible probe reaches the reservoir, lighting improves visibility and three-color LEDs indicate result levels. Select the correct fluid and keep the probe clean. Results support maintenance; they do not directly measure boiling point or certify the entire braking system.
Key capabilities
Three colors, five levels
Green is the low-moisture/normal indication, followed by yellow and red levels around 1%, 2%, 3% and at least 4%. Around 3% prompts replacement consideration; at least 4% is a high-moisture alert. Apply vehicle service requirements and professional verification.
Flexible probe and lighting
A nickel-plated probe and flexible metal hose help reach different reservoir positions. Double-click the button to toggle the probe light. Immerse only the probe as instructed and keep fluid away from the main unit.
Single-button control and power saving
Hold about 3 seconds for power, short-press for DOT3/DOT4/DOT5.1 and double-click for light. Auto sleep and audible moisture alerts assist use; power comes from 2 replaceable AAA batteries.
Suggested workflow
Prepare and select — Confirm the vehicle’s specified fluid, install 2 AAA batteries and select the fluid actually in the reservoir.
Clean and test — Clean the probe as instructed, illuminate the area and place the sensing portion in the fluid. Read when stable and avoid introducing contamination or other fluids.
Record, verify and store — Record fluid type and level; verify or replace according to service requirements if abnormal. Wipe the probe, power off and store dry.
Frequently asked questions
Are DOT5 and DOT5.1 the same fluid?
No. Silicone-based DOT5 differs from non-silicone DOT5.1. Listed selections are DOT3, DOT4 and DOT5.1; do not extend compatibility to DOT5 or mineral fluids.
Does green or a 0% level prove absolutely no water?
No. LEDs provide stepped screening affected by fluid, temperature and probe contamination. A low-moisture indication is not laboratory proof of zero water or a replacement for the service interval.
Does it measure boiling point or diagnose every braking fault?
No. It screens fluid moisture condition, not boiling point, hydraulic pressure, wear or leaks. Those require the appropriate service checks.
Product design

Documentation and support
Key features
Applications
Technical specifications
| Item | Specification or function |
|---|---|
| Model | BF100 |
| Purpose | Stepped brake-fluid moisture-condition screening |
| Fluid selections | DOT3 / DOT4 / DOT5.1 |
| Display | Three-color LEDs, five levels |
| Indication levels | Low-moisture/normal, below about 1%, about 2%, about 3%, at least 4% |
| Audible alert | High-moisture indication alert |
| Probe and sensor | Flexible metal hose and nickel-plated probe |
| Lighting | Probe LED; double-click toggle |
| Power | 2 × AAA batteries |
| Power saving | Auto sleep |
| Operating temperature | 0–50°C |
| Dimensions | 171 × 39.7 × 22 mm |
| Weight | 71 g |
| Housing | ABS |
Indicated percentages support screening; they are not boiling-point measurements or brake-safety certification. Use the correct fluid setting and follow vehicle service intervals and tool instructions.
