Battery Analyzer
BM5506/12/24 V Battery Analyzer
Analyze compatible 6/12/24 V lead-acid batteries with CCA, SOH, SOC, resistance and voltage results on a 1.8-inch backlit display. Suitable for in-vehicle or out-of-vehicle battery checks.
Product overview
The BM550 analyzes compatible 6/12/24 V lead-acid starting batteries through terminal connections, providing CCA, SOH, SOC, resistance and voltage information. Enter the battery’s correct rated value and maintain good clamp contact for comparable results. Analysis supports maintenance decisions; it does not directly measure remaining Ah capacity or predict exact service life.
Key capabilities
Multi-metric battery analysis
Review CCA, State of Health (SOH), State of Charge (SOC), resistance and voltage together. SOC and SOH are algorithmic estimates; do not base replacement solely on one percentage.
Test against the rated value
Supports Flooded, AGM flat-plate, AGM spiral, GEL and EFB lead-acid batteries. Match voltage and rating to the battery label and device menu. 100–2000 CCA is the CCA test range; do not mix rating standards.
Clear review and records
A 1.8-inch backlit display presents results. Record the entered rating, test conditions and results for later comparison.
Contact and polarity safeguards
Reverse-polarity protection and poor-contact prompts help identify connection issues. Stop and check connections when prompted; protection does not replace correct operation.
Suggested workflow
Check the battery and conditions — Verify voltage, type and rating standard; prepare the battery and handle surface charge as instructed.
Connect and enter the rating — Connect red positive and black negative to clean terminals with secure contact. Select the correct settings and enter the nameplate rating; do not guess CCA.
Interpret and recheck — Interpret voltage, SOH and SOC alongside symptoms. If undercharged, recharge and rest as instructed before retesting; retain service records.
Frequently asked questions
How do SOH, SOC and actual Ah capacity differ?
SOH estimates health and SOC estimates charge state. Neither directly measures actual Ah capacity, which requires controlled charge/discharge testing under the relevant standard.
Can it test lithium batteries or traction packs?
The listed application is lead-acid batteries within the stated voltage and type limits. Do not extend this to lithium, high-voltage traction packs or unlisted chemistries.
Why can results change on the same battery?
Clamp contact, corrosion, temperature, surface charge, vehicle loads and entered ratings affect results. Standardize conditions before comparing repeated tests.
Product design

Documentation and support
Key features
Applications
Technical specifications
| Item | Specification or function |
|---|---|
| Model | BM550 |
| Nominal battery voltages | 6/12/24 V |
| Battery types | Flooded, AGM flat-plate, AGM spiral, GEL and EFB lead-acid batteries |
| CCA range | 100–2000 CCA |
| Analysis metrics | CCA / SOH / SOC / resistance R / voltage V |
| Display | 1.8-inch backlit display |
| Test connection | Positive/negative alligator clamps |
| Use | In-vehicle / out-of-vehicle under manual conditions |
| Body dimensions | 124 × 69.6 × 22.6 mm |
| Operating input voltage | 4.9–32 V |
| Operating temperature | −20°C to 50°C |
| Protection and prompts | Reverse-polarity protection and poor-contact prompt |
SOH, SOC and CCA analysis supports maintenance; it does not guarantee actual Ah capacity or remaining service life. Use good contact, correct ratings and proper test conditions.
